The icon indicates no U.S. stock. These colors are availiable for project work with longer lead times. Contact your Surface Edge representative for details.
Lifetime Limited Residential / 12 Year Limited Medium Commercial
Packaging:
Sqft per Ctn
23.33 (7" x 48")
23.94 (9" x 48")
21.10 (12"x24")
Sqft Per Pallet
50 Ctns = 1166.5 (7" x 48")
52 Ctns = 1244.88 (9" x 48")
56 Ctns = 1181.6 (12"x24")
Sqft per Container
20 Pallets = 23330 (7" x 48")
20 Pallets = 24897.6 (9" x 48")
20 Ctns = 26632 (12" x 24")
FloorScore® conforms with the strictest VOC and indoor air quality requirements.
Comfort
The increased thickness of our Loose Lay flooring improves underfoot comfort, sound reduction, and creates a warmer floor when laid over concrete.
Waterproof
Made for projects that include areas which are commonly exposed to topical moisture. It is ideal for wet areas such as kitchens, bathrooms, break rooms, common areas, and basements. This product is unaffected by seasonal changes in relative humidity (RH) which can damage other types of flooring over time.
No Transitions
The height of our Loose Lay flooring is equal to most carpet tiles allowing the two to meet with no unsightly transitions.
Flexible Installation
Allows for limitless design creativity with endless installation layouts including herringbone, bordering, stacking, and offset installs.
Fast Installation
Loose Lay flooring combines increased weight with a specialized backing that allows it to be installed without the use of adhesives. The increased thickness hides minor subfloor irregularities which saves time and cost on subfloor preparation.
Low Cost Maintenance
UV cured Polyurethane finish requires no special maintenance procedures or equipment.
Anti-Microbial Finish
Our finish is enhanced with Nano-silver particles that kill bacteria and inhibit the growth of new bacteria on the flooring surface.
Performance Testing
Total Thickness
-
5 mm
Wear Layer
-
0.5 mm
Tile Size
-
7“ x 48”, 9” x 48”, 12" x 24"
Bevelled Edge
-
No
Classification
EN ISO 10582 EN ISO 10582 EN ISO 10582
23: Domestic Heavy 32: Commercial General 41: Light industrial Moderate
Reaction to Fire
EN13501-1 EN ISO 11925-2 EN ISO 9239-1
Bfl – S1 Pass Pass
Resistance to Chemicals
EN 423 ASTM F 925
Class 0 Pass
Resistance to Light
EN ISO 105-B02 ASTM F 1515
≥ 6 < 8
Wear Resistance
EN 660-2 ASTM F 510
Wear Group : P
Dimensional Stability
EN 434 ASTM F 2199
≤ 0.25 % Pass
Acoustic Impact Noise Reduction
EN ISO 717-2 EN ISO 140-8
Lw= 17 dB
Static Electrical Propensity
EN 1815
Voltage: 0.5kV
Residual Indentation
EN 433 ASTM F 1914
≤ 0.1 mm < 8 %
Anti-Slip Property
DIN 51130
R10
VOC Emission
ISO 16000
A+
Phthalates
EN 14372 CPSC-CH-C 1001-09.3
N.D Pass
Castor Chair Continuous Use
ISO 4918
Pass
Layers
1
Protective Coating
UV cured polyurethane enhanced with anti-microbial treatment
2
Wear Layer
Clear PVC film that increases durability and extends the life of the floor
3
Décor Layer
High resolution print film can be made to look like any surface
4
Core Layer
Waterproof core material is flexible for ease of installation
5
Fiber Glass Layer
Helps stabilize the product when faced with changes in temperature
6
Core Layer
Waterproof core material is flexible for ease of installation
7
Balance Layer
A rigid layer of PVC that counteracts forces from top to bottom
8
Backing Layer
Unique pattern of directional ridges provides anti slip properties
